Manufacturer~Description
RAB Lighting Inc.
Standards/Approvals
DLC Premium Listed|RoHS Compliant|BAA Compliant|UL Listed|IESNA LM-79 and LM-80|IP65
Warranty
5 Years
Manufacturer~Code
SLIM22-S-30
Package Fields
Package Description: Package Description: EACH
Package Height: 10.71
Package Height UOM: in
Package Length: 6.06
Package Length UOM: in
Package Quantity: 1
Package Weight:
Package Weight UOM:
Package Width: in
Package Width UOM: in
Amperage Rating
0.28/0.17/0.15/0.13 A
Amperage Rating UOM
A
Average Life
100000 hr
Average Life UOM
hr
Ballast Type
Class 2/Constant Current/0 to 10 V Dimming
Color Rendering Index (CRI)
83 to 86
Color Temperature
3000/4000/5000K K
Color Temperature UOM
K
Dimensions
8 in H x 9-7/16 in W x 4-3/4 in D
Enclosure Type
IP65
Fixture Wattage
15.5 to 32.8 W
Fixture Wattage UOM
W
Housing Finish
Bronze
Housing Material
Die-Cast Aluminum
Lamp Type
LED
Lamp Wattage
30/25/20/15 W
Lamp Wattage UOM
W
Lens Type
Polycarbonate
Light Output
135.9 to 158.5 Lumens/W
Light Output UOM
Lumens/W
Mounting Type
Hinged
Series
SLIM
Member SKU ID
406569898
AD SKU ID
CAX_0125_ROVR7D1_436
Voltage Rating
120/208/240/277 V
Voltage Rating UOM
V
Lumens
2199 to 4833 Lumens
Lumens UOM
Lumens
- Brand Code: 14215
- Brand Description: RAB
- Country: USA
- Amperage Rating: 0.28/0.17/0.15/0.13
- Amperage Rating UOM: A
- Average Life (HR): 100000
- Ballast Factor: nan
- Ballast Grade: nan
- Ballast Load (VA): nan
- Ballast Type: Class 2/Constant Current/0 to 10 V Dimming
- Beam Angle: nan
- Beam Angle UOM: nan
- Warranty: 5 Years
- Standards/Approvals: DLC Premium Listed|RoHS Compliant|BAA Compliant|UL Listed|IESNA LM-79 and LM-80|IP65
