Manufacturer~Description
Intermatic
Standards/Approvals
UL Recognized, CSA, Title CA 20 Listed, California Title 24 Compliant
Warranty
2 Years
Manufacturer~Code
K4023C
Includes
Weatherproof Wall Plate, Neoprene Gasket
Package Fields
Package Description: Package Description: EACH
Package Height: 4.88
Package Height UOM: in
Package Length: 3
Package Length UOM: in
Package Quantity: 1
Package Weight: 0.18
Package Weight UOM: lb
Package Width: in
Package Width UOM: in
Amperage Rating
15 A
Amperage Rating UOM
A
Ballast Load
1700 to 2300 VA
Ballast Load UOM
VA
Color
Gray
Contact Form
SPST
Dimensions
46 mm H x 23.8 mm W x 20.6 mm D
Environmental Conditions
-40 to 158 deg F
Environmental Conditions UOM
deg F
Frequency Rating
50/60 Hz
Frequency Rating UOM
Hz
Material
Polycarbonate
Mounting Type
Box/Fixture
Sensitivity
1 to 5 FC ON/3 to 15 FC OFF
Series
K4000
Timing Range
30 to 90 s
Timing Range UOM
s
Tungsten Rating
3100 to 4150 W
Tungsten Rating UOM
W
Wire Size
18 AWG
Wire Size UOM
AWG
Member SKU ID
406569856
AD SKU ID
IDW_8411062
Type
Thermal
Voltage Rating
208 to 277 V AC
Voltage Rating UOM
V AC
- Brand Code: 9682
- Brand Description: Intermatic®
- Country: USA|Canada
- Amperage Rating: 15
- Amperage Rating UOM: A
- Average Life (HR): nan
- Ballast Factor: nan
- Ballast Grade: nan
- Ballast Load (VA): 1700 to 2300
- Ballast Type: nan
- Beam Angle: nan
- Beam Angle UOM: nan
- Warranty: 2 Years
- Standards/Approvals: UL Recognized|CSA Certified|Title CA 20 Listed|California Title 24 Compliant
