Manufacturer~Description
Intermatic
Standards/Approvals
ANSI C136.24 Compliant, UL Certified to US, CSA Certified to Canadian, Title CA 20 Listed
Warranty
8 years
Manufacturer~Code
EK4036S
Package Fields
Package Description: Package Description: EACH
Package Height: 4.88
Package Height UOM: in
Package Length: 1.75
Package Length UOM: in
Package Quantity: 1
Package Weight: 0.2
Package Weight UOM: lb
Package Width: in
Package Width UOM: in
Amperage Rating
{0}
Amperage Rating UOM
A
Arrester
255 J
Arrester UOM
J
Ballast Load
1800 VA
Ballast Load UOM
VA
Color
Gray
Dimensions
2.25 in H x 1.3 in W x 1.24 in D
Enclosure Type
NEMA 4/10
Environmental Conditions
-40 to 158 deg F Operating Temperature
Frequency Rating
50/60 Hz
Frequency Rating UOM
Hz
Material
Polycarbonate
Mounting Type
Box
Operating Cycles
10000 Cycles
Operating Cycles UOM
Cycles
Sensitivity
1.5 FC On/2.25 FC Off
Sensor Type
Solid State Photo/Silicon IR Filtered
Timing Range
2 to 5 s
Timing Range UOM
s
Tungsten Rating
1000 W
Tungsten Rating UOM
W
Wire Size
18 AWG
Wire Size UOM
AWG
Member SKU ID
406569839
AD SKU ID
IDW_13098617
Type
Button
Voltage Rating
105 to 305 V AC
Voltage Rating UOM
V AC
- Brand Code: 9682
- Brand Description: Intermatic®
- Country: USA|Canada
- Amperage Rating: 6
- Amperage Rating UOM: A
- Average Life (HR): nan
- Ballast Factor: nan
- Ballast Grade: nan
- Ballast Load (VA): 1800
- Ballast Type: nan
- Beam Angle: nan
- Beam Angle UOM: nan
- Standards/Approvals: ANSI C136.24 Compliant|UL Certified to US|CSA Certified to Canadian|Title CA 20 Listed
